| STUD DIAMETER | "A" DIMENSION | "B" DIMENSION | PART NUMBER |
|---|---|---|---|
| 2mm | 0.079 | 2.50 | CN-002M |
| #2 | 0.086 | 2.50 | CN-008 |
| #4 (12 Ga.) | 0.112 | 2.50 | CN-010 |
| #5 (1/8) | 0.125 | 2.50 | CN-012 |
| #6 (10 Ga.) | 0.138 | 2.50 | CN-013 |
| 4mm | 0.158 | 2.50 | CN-004M |
| #8 | 0.164 | 2.50 | CN-016 |
| #10 | 0.190 | 2.50 | CN-019 |
| 5mm | 0.196 | 2.50 | CN-005M |
| 0.215 | 0.215 | 2.50 | CN-021 |
| 6mm | 0.236 | 2.50 | CN-006M |
| 1/4 | 0.250 | 2.50 | CN-025 |
| 5/16 | 0.312 | 2.50 | CN-031 |
| 8mm | 0.315 | 2.50 | CN-008M |
| 0.33 | 0.330 | 2.50 | CN-033 |
| 3/8 | 0.375 | 2.50 | CN-037 |
| 10 mm | 0.394 | 2.50 | CN-010M |
| 7/16 | 0.437 | 2.50 | CN-043 |
| 12mm | 0.472 | 2.50 | CN-012M |
| 1/2 | 0.500 | 2.50 | CN-050 |
| 14mm | 0.551 | 2.50 | CN-014M |
| 9/16 | 0.562 | 3.00 | CN-056 |
| 5/8 | 0.625 | 3.00 | CN-062 |
| 16mm | 0.630 | 3.00 | CN-016M |
| 0.68 | 0.680 | 3.00 | CN-068 |
| 18mm | 0.709 | 3.00 | CN-018M |
| 3/4 | 0.750 | 3.00 | CN-075 |
| 20mm | 0.787 | 3.00 | CN-020M |
| 7/8 | 0.875 | 3.00 | CN-087 |
| 1 | 1.000 | 3.00 | CN-100 |
